Frontlit Banner
YIDU offers frontlit banners in weights ranging from 240g to 510g (7oz to 15oz) with both glossy and matte finishes. Our banners are compatible with UV, latex, sublimation, solvent, and eco-solvent printing technologies. Available in widths of up to 5m, they are suitable for a variety of large-format applications.
Frontlit Banner Data Sheet
| Flex Banner | |
|---|---|
| Coating Material | PVC |
| Production | Cold Lamination & Hot Lamination |
| Type of yarn | Polyester |
| Finish | Glossy/Matte |
| Width | 1.02-3.2/4.2/5.1M |
| Length | 50/70/80/100M |
| Ink type | UV/Eco solvent/Solvent |
| Packing | Craft paper/Hard tube packing |
| Temperature | From -30℃ to 70℃ |
| Flame Retardant | B1,B2,M1,M2,NFPA-701,CAPI-84 Optiona |
| RF weldable (heat sealable) | Acrylic or PVDF Optiona |
| Other Optional | Ecofriendly, UV, Anti-Mildew, Aging Resistance, Cold Resistance, Optional |
| To be customized | Color, Softness, and other details |
Advantage
Suitable for printer: Vutek, Hp-Scitex, Nur, DGI, Mimaki, Roland, Mouth, Seiko JET-I etc.
Perfect ink absorption and fast dry.
Could reach: REACH, SGS, B1
Glossy and Matt both available.
Low cost choice.
Ready To Be Our Next Trusted Partner?
Looking for the perfect solution for your project? Fill out the form on our website and tell us your specific requirements. Whether it's product details, pricing, or customization options, our team is here to provide a tailored quote just for you.
Standard Size
| Weight/Oz | Yarn | Size(m) | |
|---|---|---|---|
| 240±10/7oz | 200*300D,18*12 | 1.02-3.2x50/80/100m | Normal/High intensity |
| 260±10/7.5oz | 200*300D,18*12 | ||
| 280±10/8oz | 200*300D,18*12; 500*500D,9*9 |
||
| 320±10/9.5oz | 200*300D,18*12 | 1.02- 3.2x50m |
|
| 340±10/10oz | 200*300D,18*12 | ||
| 380±10/11oz | 300*500D,18*12 500*500D,9*9 |
||
| 440±10/13oz | 300*500D,18*12; 840*840D,9*9; 1000*1000D,9*9 |
||
| 510±10/15oz | 300*500D,18*12 | ||
| Extra1 | Test | 1.02-3.2x50m | No Scroll |
| Extra2 | Test | 1.02-3.2x50m | No Scroll |
| Extra3 | Test | 1.02-3.2x50m | No Scroll |
| Extra4 | Test | 1.02-3.2x50m | No Scroll |
Let Us Know Your Needs
(Usually) if in stock, MOQ 10 rolls, if not in stock, MOQ 40 rolls
Our Guarantee Promise
PVC Banner Material Loading into Container
100% Full Reimbursement Service
● Product issues? No worries! If you encounter any quality issues while using our products, we will provide a full reimbursement service to ensure your satisfaction.
● Issues during transportation? We’ve got you covered there too! If any damage or other issues occur during the transportation of the product, we will fully reimburse you to ensure the safe delivery of your order.
Whatever the problem, we will do our utmost to ensure that your shopping experience is smooth and enjoyable. Your satisfaction is our ultimate pursuit.
